PowerMon Kolorimeter Online Analyzer
PowerMon Kolorimeter - Online Measuring Instrument
FEATURES
The PowerMon Kolorimeter is a versatile applicable online measuring instrument. It guarantees a permanent optimal water quality by the continuous supervision of the legally prescribed limit value for total phosphate and ortho-phosphate in the outlet of municipal and industrial purification plants.
Apart from higher precision and shortening of the measuring cycles the PowerMon offers a special highlight: For the measurement of most diverse parameters (e.g. oxygen, pH, redox, conductivity etc.) the connection of various sensors is possible!
For the individual sensors the PowerMon automatically takes over the functions of a transducer. It is also possible to set the separate results against each other.
A remote supervision enables the permanent control of the correct function of your plant. The highest possible data transfer over the interfaces, as well as the operation of the PowerMon via the touch screen user interface ensures an easy and user friendly operation.
The compact and modular design of the PowerMon can contain up to six on-line measuring points in one device and enables a space-saving and economic operation.
| Measuring methods | cyclic, colorimetric |
|---|---|
| Measuring cycle | typ. 10 - 15 min. |
| Measuring range |
Further parameters and measuring ranges on request. |
| Precision | depending on the application* |
| Drift | depending on the application* |
| Number of measuring points | max. 6 |
| Output signal |
|
| Interfaces |
USB / Ethernet Option:
|
| Relay contacts | 4/12 potential free contacts free allocable (e.g. alarm contact) |
| Digital inputs | 4/12 e.g. activating and deactivating of measuring points, system control |
| Sample | pressure-free |
| Temperature | 15 - 45°C (288 - 318 K) |
| Flow | 3 – 10 l/h free from suspended matter and oil |
| Connection | tube, flexible (ID 1.5 - 3 mm) |
| Drain | pressure-free tube, flexible (ID 10 mm) |
| Power supply | 85…264 VAC at 47…63 Hz |
| Power consumption | max. 150 VA |
| Environmental temperature |
15 - 35°C (288 - 308 K) |
| Installation | wall-mounted |
| Protection class |
(EN 60529)
|
| Weight | housing with reagent cabinet 53 - 60 kg without reagents |
| Dimensions | housing: 700x600x320 mm with reagent cabinet: 1100x600x354 mm |
DIMENSIONS & SPECIFICATIONS
Technical Data
Technical Data
| Measuring methods | cyclic, colorimetric |
|---|---|
| Measuring cycle | typ. 10 - 15 min. |
| Measuring range |
Further parameters and measuring ranges on request. |
| Precision | depending on the application* |
| Drift | depending on the application* |
| Number of measuring points | max. 6 |
| Output signal |
|
| Interfaces |
USB / Ethernet Option:
|
| Relay contacts |
4/12 potential free contacts free allocable (e.g. alarm contact) |
| Digital inputs | 4/12 e.g. activating and deactivating of measuring points, system control |
| Sample |
pressure-free Temperature: 15 - 45°C (288 - 318 K) Flow: 3 – 10 l/h free from suspended matter and oil Connection: tube, flexible (ID 1.5 - 3 mm) |
| Drain | pressure-free tube, flexible (ID 10 mm) |
| Power supply |
85…264 VAC at 47…63 Hz Power consumption: max. 150 VA |
| Environmental temperature | 15 - 35°C (288 - 308 K) |
| Installation | wall-mounted |
| Protection class (EN 60529) |
|
| Weight |
housing with reagent cabinet 53 - 60 kg without reagents |
|
Dimensions (HEIGHT X WIDTH X DEPTH) |
housing: 700x600x320 mm with reagent cabinet: 1100x600x354 mm |
